Powering Your Life Sustainably
Efficient
The HYS-LV-US Series single-phase hybrid inverters are a great choice for those looking for an affordable and efficient way to power their homes.
- These inverters boast a maximum efficiency of 97.6% and a CEC efficiency of 97.0%.
- With a DC/AC ratio of up to 150%, they can handle high amounts of solar power.
Seamless
The HYS-LV-US Series inverters also offer seamless backup power for your whole home or critical loads in the event of a power outage.
- This series supports 120V/240V backup power without an external autotransformer.
- The inverters come with a built-in dry contact that can be flexibly set to earth fault alarm, load control, or generator control.
Features
The HYS-LV-US Series includes:
- Double MPPT tracker, up to 32 A MPPT current
- Max. Efficiency 97.6%, CEC Efficiency 97.0%
- DC/AC ratio up to 150%
- Seamless backup power for whole home or critical loads
- Support 120 V/240 V backup power without external autotransformer
- Built-in dry contact flexibly set to earth fault alarm, load control or generator control
- Ultralight for easy installation and space-saving
- Integrated arc fault protection and rapid shutdown function
The intelligent EMS function supports:
- Self-consumption mode
- Economic mode
- Backup mode for multi-scenario applications
Monitoring management through S-Miles Cloud allows users to remotely diagnose and track individual system's performance over time, maximizing the total solar power production and battery utilization.
The HYS-LV-US Series is compatible with:
- Li-ion batteries
- Lead-acid batteries
Empower Your Energy Future
Further Details
Hoymiles Batteries
Compatible with cutting-edge Hoymiles batteries for efficient energy storage.
Certifications & Standards
Soluna Compatible
Works seamlessly with Soluna batteries for reliable power backup.
